Straightaway 100

SKU STRAIGHTAWAY-100

Straightaway 100 is a top hung sliding door system for heavier weight doors. It can be used internally and externally and is suited to applications where large sliding doors are required to slide effortlessly such as room dividers and room entrances. It is an easy to fit reliable system.

Overview

Top hung sliding system for timber or metal doors up to 100kg

  • Ideal for residential and commercial applications
  • Smooth and quiet operation provided by aluminium track and nylon rollers
  • Soffit or wall fixing available
  • Hangers vertically and laterally adjustable to ensure a perfect fit
  • Range of bottom guiding options available to achieve a clear threshold
  • Suitable for single or multiple track layouts
  • Any number of doors can be used on single or multiple lines of track to cover the width of the opening
  • Tracks can be mounted directly to the soffit or wall mounted using brackets
  • Self-closing and Soft closing options available for both soffit or wall mounted┬átrack
  • Telescopic opening options for 2 doors and 3 doors available
  • Simultaneous opening option available for bi-parting doors
  • Straightaway 100SS with 316 grade stainless steel components is available for use in harsh operating environments
  • Straightaway 100 is available in 1 door tracksets for openings up to 2400mm with additional aluminium track and components available for larger openings.





TECHNICAL SPECIFICATIONS
Weight
100
Thickness
20mm - 50mm
Height
2700mm
Closure Type
Sliding
Door Material
Metal
Timber
Fitting Position
Top Hung
