Flat Track 100 – Straight

SKU FLAT TRACK STRAIGHT

Flat Track 100 is a simple “barn door” style hardware system with exposed fittings for a rustic look. The straight hangers are one of many choices of styles available and are perfect for interior home renovation projects.

Overview

Top hung sliding system for timber doors up to 100kg

  • Available in black, rust and brushed stainless steel finishes
  • For single, bi-parting doors or bi-passing doors *
  • No bottom track required to allow for a clear threshold for most layouts **
  • Precisely machined steel strap nylon wheels providing smooth operation
  • Solid feel with side fixed steel top track
  • Soft close and soft open available ***
  • Flat Track is available in 1 door tracksets for doors up to 1500mm wide. For bi-parting doors and larger openings jointing kits and splice plates are available

*       41032/41024/41025 brackets are needed for bi passing doors – 5 for doors up to 1000mm and 7 for doors up to 1500mm

**     For bi passing doors sliding outside of an opening, please contact our technical team for advice on guiding options

***   Minimum door width 500mm when using soft open and soft close

PRODUCT GALLERY
TECHNICAL SPECIFICATIONS
Weight
100
Thickness
35mm - 44mm
Closure Type
Sliding
Door Material
Timber
Fitting Position
Top Hung
